DTS-2.0 Telescopic Boom Emery Topping Spreader
Short Description:
DTS-2.0 is an efficient concrete emery material spreader.
This machine is especially suitable for cooperating with other laser leveling machines produced by DYMAMIC to complete the subsequent spreading of emery materials. With the control of emery technology, users can accurately control the amount of material spread per square meter. The whole process is mechanized, avoiding various construction problems such as uneven material spread, dust and on-site footprints. It is an ideal choice to achieve the overall construction of large area of emery flooring.
| Product Name | topping spreader |
| Model | DTS-2.0 |
| Dimension | L5150XW2320XH1960 (mm) |
| One-time material spreading area | 10.8 (m²) |
| Extension length of spreading head | 6000 (mm) |
| Spreading head width | 1800 (mm) |
| Fispensing hoopper capacity | 240 (kg) |
| Walking speed | 0-10 (km/h) |
| Walking drive | hydraulic motor four-wheel |
| Engine | Changfa CF3B |
| Power | 20 (Kw) |
The machines may be upgraded without further notice, subject to the actual machines.
1. Large storage space for vehicle load materials and convenient to use.
2. Convenient feeding and discharging.
3. Good accuracy of spreading.
4. Low dust technology.
5. Simple operation and convenient maintenance/ repair.
1. Standard seaworthy packing suitable for long-distance transportation.
2. The transportation packing of plywood case.
3. All of the production are inspected carefully one by one by QC before delivery.
| Lead Time | |||
| Quantity(pieces) | 1 - 1 | 2 - 3 | >3 |
| Est.time (days) | 7 | 13 | To be negotiated |
Shanghai Jiezhou Engineering & Mechanism Co., Ltd.(hereinafter referred to as “DYNAMIC”) is a professional manufacturer producing world-class concrete products for Road Industry. Located in Shanghai city of China, Dynamic established since 1983 and has been involved in a wide variety of road construction projects all around the domestic and overseas. DYNAMIC are based on humanism design, our product feature good appearance, reliable quality and stable performance which make you feel comfortable and convenient during the operation. They have been certified by ISO9001 Quality System and CE Safety System.
Q1: Are you manufacture or trade company?
A: Of course, we are manufacturer and we have our own factory. We can offer you best products and best services.
Q2: How about your delivery time?
A: Generally, it will take 3 days after payment arrived.
Q3: What is your terms of payment?
A: T/T, L/C, MasterCard, Western Union.
Q4: What is your packaging?
A: We package in Plywood case.
Q5: Do you machine can be custom-made?
A: Yes, we can design and produce according to client's requirements.
