DUR-380
DUR-380 plate compactor is designed with double eccentric blocks, with a compaction force of 40kN, large tamping strength and good vibration effect. The ram plate is made of nodular cast iron, with an integrated casting process, high strength, crack resistance, and durability.
The directional control operation is completed by the hydraulic system. The high-precision hydraulic system ensures the reliability and durability of the system.
-
hur-300 BEST SALE WACKER ductile iron casting diesel plate compactor
Dynamic HUR-300 walk behind plate compactor has a very reasonable design. The weight and size of the machine are perfectly balanced.
With a deadweight of 174 kg and a compaction capacity of 30 kN, it can not only effectively compact the subgrade backfill, but also easily compact the asphalt pavement.
Well made hydraulic control system, fast forward and backward speed, flexible and easy to operate.
-
dur-400 hydraulic reversible plate compactors
The vibrating plate compactor is mainly suitable for compacting materials with low adhesion and friction between particles, such as river sand, crushed stone, and asphalt. The main working parameters of a vibrating plate compactor include: bottom area of the working plate, overall mass, excitation force, and excitation frequency. In general, the bottom plate area of the same specification of flat plates is similar, so the performance of flat plate impact compactors is mainly affected by the overall quality, excitation force, and excitation frequency of the machine. The excitation force is mainly used to maintain the forced vibration of the compacted material; The excitation frequency affects the compaction efficiency and degree, that is, under the same excitation force, the higher the excitation frequency, the higher the compaction efficiency and compactness.
-
DUR-400 Double direction hand held germany vibartory hydraulic plate compactor
The bidirectional flat compactor is mainly used in compaction operations, especially for compaction operations in narrow tunnels, and can be used for compaction of engineering foundations and asphalt pavement. And it has some characteristics, which are:
(1) Easy to start and smooth operation;
(2) The bottom plate of the flat compactor is made of manganese alloy steel or ductile iron material, which has good wear resistance;
(3) Its surface has been sprayed with plastic, with a magnesium gloss appearance, and it can also prevent rust and corrosion.
The working principle of a bidirectional flat compactor is as follows: the engine in the flat compactor drives the eccentric to generate vibration through the clutch and pulley, and the bottom plate and eccentric are fixed together. To change the direction of vibration, it can be achieved by rotating the eccentric block. Furthermore, to achieve forward vibration, in-place vibration, and backward vibration.
-
DUR-600 Two eccentric blocks 60kN pressure strength Large tonnage vibrating plate compactor
Newly designed DUR-600 plate compactor has a tamping capacity of 60kN. It has the advantages of small size and large tamping strength. The size of the fuselage is only equivalent to that of the HUR-300, and the tamping strength is twice that of the HUR-300 (30 kN for the HUR-300).
The top cylindrical roller bearing is adopted, with high speed and reliability. The key ramming plate material is made of high-strength and wear-resistant ductile iron to ensure the quality.
It is mainly used for subgrade compaction, slope surface (embankment), bench compaction, groove pit compaction and other complex foundation compaction.
-
HUR-250 Hydraulic control reversible two-way vibrating plate compactor
DYNAMIC HUR-250 hydraulic two-way plate compactor, equipped with Honda GX-160 engine as standard, has strong power and simple.maintenance. In addition, the engine meeting EPA certification is optional.
This machine are ideal for curbs, gutters, around tanks, forms, columns, footings, guard railings, drainage ditches, gas and sewer works and building construction.
It is sold all over the world and is well received by customers.
-
HZR-80 Honda GX-160/Briggs Stratton gasoline engine vibrating plate compactor
This machine are ideal for curbs, gutters, around tanks, forms, columns, footings, guard railings, drainage ditches, gas and sewer works and building construction. The asphalt models are suitable for hot or cold asphalt applications in confined areas.Optimally suited for a variety of compaction applications due to high travel speeds and ease of maneuverability. Guide handle with patented vibration dampening increase operator comfort and reduces fatigue. The large capacity water tank and the wide filler opening improve productivity. Tough ductile iron baseplate is extremely durable even under extremely conditions and provides for long service. Optional wheel kit offer easier moving and transport.
-
HUR-300 Best in weight and size Hydraulic Reversible Plate Compactor
Dynamic HUR-300 walk behind plate compactor has a very reasonable design. The weight and size of the machine are perfectly balanced.
With a deadweight of 174 kg and a compaction capacity of 30 kN, it can not only effectively compact the subgrade backfill, but also easily compact the asphalt pavement.
Well made hydraulic control system, fast forward and backward speed, flexible and easy to operate.
-
DUR-1000 100kN pressure strength All hydraulics large Plate compactor
DUR-1000 plate compactor is the largest plate compactor of DYNAMIC. Its weight of 725kg and compaction force of 100kN demonstrate its strength as a heavy tank.
Lombardini diesel engine is adopted, which is powerful, reliable and durable.
The main hydraulic pump is driven by the engine, and the hydraulic motor is directly connected with the eccentric block, power transmission is efficient and the system design is reliable, which is the best scheme in the field of plate compactor.
-
DUR-400 40kN vibration force Forward and backward two-way hydraulic control plate compactor
DUR-400 plate compactor is designed with double eccentric blocks, with a compaction force of 40kN, large tamping strength and good vibration effect. The ram plate is made of nodular cast iron, with an integrated casting process, high strength, crack resistance, and durability.
The directional control operation is completed by the hydraulic system. The high-precision hydraulic system ensures the reliability and durability of the system.
-
HZR-90 Factory production and sales of 20kN vibrating plate compactor
This flat compactor is the sales champion among one-way flat compactors. It uses Honda/Briggs Stratton 5.5 horsepower gasoline engine, and diesel engine can also be selected. The machine has a vibration force of 20 kN, which is powerful and has good vibration effect.
Optional: water tank, sprinkle water during construction on asphalt; Vibration damping pad, construction when laying floor tiles; The traveling wheel makes it easier to transfer.
Ram plate size: 590 × 500mm（23.2 × 19.6 inches), made of ductile iron, solid and durable.
-
DUR-500 428 kg CE certified diesel gasoline engine vibrating plate compactor
DUR-500 plate compactor, with a dead weight of 428 kg and a pressing capacity of 50 kN (about 5 tons), has excellent design and excellent manufacturing technology to ensure the perfect performance of the machine during operation.
Honda GX-390 engine is equipped as standard, with a power of 13 horsepower, strong power and simple maintenance. It is easy and fast to start with one button electronic ignition. There are also high-quality diesel engines to choose from. In addition, engines meeting EPA certification can be selected.
